Empty Can Test

 Empty Can Test


Empty can test or as it called Jobe Supraspinatus Test is used to check for weakness or insufficiency of the supraspinatus muscle and rotator cuff impingement of the shoulder.

It was first described by Christopher M. Jobe, MD, an Orthopedic surgeon in Oroville, California.

How do you perform the empty can test?

  • Empty can test may be performed with the patient standing or seated, with the examiner stands facing the patient. The examiner hand is placed on the superior portion of the midforearm to resist the motion of abduction in the scapular plane.
  • With the elbow extended, the patient’s arm is held at 90 degrees of abduction, 30 degrees of horizontal flexion, and in internal rotation.
  • The examiner exerts pressure on the upper arm during the abduction and horizontal flexion motion.
  • Using electromyography EMG, this test enables testing of the supraspinatus muscle largely in isolation.
  • It is important to apply pressure gently at first and to increase the pressure only if pain has not been triggered during the course of the test to that point.

Although this test isolates the supraspinatus muscle-tendon unit, clinical weakness can be simulated by the presence of significant pain. To alleviate some of this pain and to more directly evaluate supraspinatus strength, the test can be repeated with the thumbs pointed upward (the “full can” position) the so called a full can test.

See Also: Rotator Cuff of the Shoulder
Empty can Test
Jobe test in the “empty can” position: In this test, both arms are placed in approximately 90° of abduction within the scapular plane and maximally internally rotated (thumbs pointed downward). The patient then attempts to further abduct the humerus against resistance applied by the examiner. A positive test occurs when asymmetric weakness occurs involving the affected shoulder.
Empty can Test Jobe test
Empty Can Test with the Elbow Flexed

Full Can Test:

  • This test is done with the patient standing or sitting.
  • Similar to the empty can test, the elbow is extended and the patient’s arm is held at 90° of abduction, 30° of horizontal flexion, and in external rotation.
  • Then the examiner applies a pressure on the examined limb.
  • A positive test occurs when asymmetric weakness occurs involving the affected shoulder.
  • This variation of the Jobe test is thought to reduce the pain associated with supraspinatus impingement and may be more sensitive to actual weakness rather than guarding due to impingement.
  • This maneuver is thought to position the greater tuberosity away from the coracoacromial arch and may therefore decrease the pain associated with mechanical cuff impingement.
full can test
Jobe test in the “full can” position: Both arms are placed in approximately 90° of abduction within the scapular plane and externally rotated (thumbs pointed upward). The patient then attempts to further abduct the humerus against resistance applied by the examiner.

What does a positive Empty Can Test mean?

  • When Jobe Test elicits severe pain and the patient is unable to hold his or her arm abducted 90° against gravity, this is called a positive drop arm sign.
  • The superior portions of the rotator cuff (supraspinatus muscle) are particularly assessed in internal rotation (with the thumb down as when emptying a can), and the anterior portions in external rotation (thumb points upward – full can).
  • The Empty Can Test may be repeated at only 45° abduction to further differentiate the findings.
  • Where the impingement component predominates, there will be less pain and more strength where the tendon is still intact.
  • The Empty Can Test can yield false-positive results where pathology of the long head of the biceps tendon is present.
  • If the test elicits pain and the patient is unable to abduct the arm 90° and hold it against gravity, this indicates a tear of the tendon of the supraspinatus muscle, or damage to the suprascapular nerve.
  • Strength in the supraspinatus muscle may not be completely diminished until over two-thirds of the tendon is torn.

Empty Can Test Accuracy

A Cohort Study 1 by Nitin B Jain found that empty can test had a high sensitivity and specificity for supraspinatus tears as following:

  • Sensitivity: 88 %
  • Specificity: 62 %

Another study 2 found the empty can test to have a high sensitivity of 86% and a low specificity of 50% in diagnosing supraspinatus tendon tears in a series of 55 patients.

The full can test had higher specificity (74% vs. 68%) and an equal sensitivity of 77% when compared with the empty can test in a series of 136 patients 3.

Diagnostic Utility of the Empty Can Test in Identifying Subacromial Impingement:

Description and Positive FindingsPopulationReference StandardSensitivitySpecificity+LR-LR
The examiner asks the patient to elevate and internally rotate the arm with thumbs pointing downward in the scapular plane. The elbow should be fully extended. In this position the examiner applies downward pressure on the upper surface of the arm. Test is positive with weaknessPooled estimates from six studies (n = 695)Impingement syndrome diagnosed by arthroscopy.69 (.54, .81).62 (.38, .81)1.8.50
Examiner elevates patient’s shoulder to 90 degrees in the scapular plane and then places the shoulder in internal rotation by asking the patient to rotate the shoulder so that his or her thumb is pointing toward the floor. The examiner then applies a downward directed force at the wrist while the patient attempts to resist. Test is considered positive if weakness is detected of the involved shoulder as compared bilaterally55 patients with shoulder painImpingement diagnosed via arthroscopy.50 (.26, .75).87 (.77, .98)3.9 (1.5, 10.1).57 (.35, .95)

Starter Test

Starter Test or Zero-Degree Abduction Test is another test for rotator cuff tear especially the Supraspinatus tendon.

The patient stands with his or her arm s hanging relaxed. The examiner grasps the distal third of each forearm. The patient attempts to abduct the arms against the examiner’s resistance.

Abduction of the arm is “started” by the supraspinatus and deltoid muscles. Pain and, especially, weakness in abducting and holding the arm strongly suggest a rotator cuff tear.

Zero-degree abduction test
Zero-degree abduction test ( Starter Test )

Notes

  • Studies performed by anesthetizing the suprascapular and axillary nerves show that the supraspinatus and deltoid muscles are responsible for abduction of the arm.
  • The supraspinatus muscle, along with the other muscles of the rotator cuff , press the head of the humerus into the socket and abduct the arm for the first 20°, then the deltoid muscle comes into play.
  • Even if the supraspinatus muscle tendon is completely torn, the shoulder is still capable of good range of motion.
  • There is a deficit only at the onset of abduction and then again when the arm reaches 90° and above.
  • EMG tests show no difference in the EMG activity whether the arm is held in full internal rotation (classic Jobe empty can position), with the thumb pointing to the floor, or with the arm in maximum external rotation (full can position).
  • The strength of the supraspinatus muscle can also be tested with the elbows flexed rather than extended.
  • For the patient, this position requires less holding power and less stress, and is therefore also less painful.
  • A partial rupture of the supraspinatus tendon will result in abduction that is both weak and painful. A painless weakness with abduction could indicate a complete rupture of the supraspinatus tendon, although the deltoid cannot be ruled out. The tendon of the supraspinatus can be passively stretched by positioning it in adduction and IR to see if this increases the pain.
  • Eccentricity of the humeral head in the form of superior displacement of the humeral head in a rotator cuff tear causes relative insufficiency of the outer muscles of the shoulder. Small tears that can be functionally compensated for will cause minor loss of function with the same amount of pain. Larger tears are invariably characterized by weakness and loss of function.
  • The empty can test and full can test are about equally accurate in detecting supraspinatus tears. Because the full can test is less pain provoking of impingement symptoms, its use is recommended.
  • Pain in the absence of weakness does not help detect partial-thickness tears or tendinopathy.

Related Anatomy

There are four rotator cuff muscles (supraspinatus, infraspinatus, teres minor, subscapularis muscles).

Supraspinatus muscle originates from Superior scapula and inserts onto Humerus Greater tuberosity. It’s innervated by Suprascapular nerve.

Its action is abducting and externally rotating the arm, providing stability to the shoulder joint.

Rotator Cuff Anatomy
Rotator Cuff Anatomy

References

  1. Nitin B Jain, Jennifer Luz, Laurence D Higgins, Yan Dong, Jon J P Warner, Elizabeth Matzkin, Jeffrey N Katz. The Diagnostic Accuracy of Special Tests for Rotator Cuff Tear: The ROW Cohort Study.Am J Phys Med Rehabil. 2017 Mar. PMID: 27386812.
  2. Leroux JL, Thomas E, Bonnel F, Blotman F. Diagnostic value of clinical tests for shoulder impingement syndrome. Rev Rhum Engl Ed. 1995 Jun;62(6):423-8. PMID: 7552206.
  3. Itoi E, Kido T, Sano A, Urayama M, Sato K. Which is more useful, the “full can test” or the “empty can test,” in detecting the torn supraspinatus tendon? Am J Sports Med. 1999 Jan-Feb;27(1):65-8. doi: 10.1177/03635465990270011901. PMID: 9934421.
  4. Litaker D, Pioro M, El Bilbeisi H, et al. Returning to the bedside: using the history and physical examination to identify rotator cuff tears. J Am Geriatr Soc. 2000;48:1633-1637
  5. Jobe FW, Moynes DR. Delineation of diagnostic criteria and a rehabilitation program for rotator cuff injuries. Am J Sports Med. 1982;10:336–9.
  6. Alqunaee M, Galvin R, Fahey T. Diagnostic accuracy of clinical tests for subacromial impingement syndrome: a systematic review and meta-analysis. Arch Phys Med Rehabil. 2012;93(2):229-236.
  7. Michener LA, Walsworth MK, Doukas WC, Murphy KP. Reliability and diagnostic accuracy of 5 physical examination tests and combination of tests for subacromial impingement. Arch Phys Med Rehabil. 2009;90(11):1898-1903.
  8. Holtby, R, and Razmjou, H: Validity of the supraspinatus test as a single clinical test in diagnosing patients with rotator cuff pathology. J Orthop Sports Phys Ther, 34:194, 2004.
  9. Campbel’s Operative Orthopaedics 13th Book
  10. Clinical Tests for the Musculoskeletal System 3rd Edition.
  11. Dutton’s Orthopaedic Examination, Evaluation, And Intervention 3rd Edition.
